Paige 459842NH 24AWG-2 Pair Stranded, Shielded, LSZH Cable

 CABLE CONSTRUCTION

 1. Conductors

 1.1 Material: Tinned Copper
 1.2 Size: 24 AWG
 1.3 Construction: 7 Strand

 2. Insulation

 2.1 Material: Polyethylene
 2.2 Wall Thickness: .020”
 2.3 Color code:
                   1) White/Blue            Blue/White
                   2) White/Orange       Orange/White

 3. Assembly

 3.1 Lay Length: 3.25” LHL (3.69 tw/ft)

 4. Shield

 4.1 Material: Aluminum Mylar tape
 4.2 Coverage: 100%

 5. Drain

 5.1 Material: Tinned Copper
 5.2 Size: 24 AWG
 5.3 Construction: 7 Strand

 6. Braid

 6.1 Material: Tinned Copper
 6.2 Size: 36 AWG
 6.3 Coverage: 90%

 7. Jacket

 7.1 Material: Low Smoke Zero Halogen Polyolefin
 7.2 Wall Thickness: .030”
 7.3 OD: .293” nom.
 7.4 Ripcord: Yes
 7.5 Color: Gray
 7.6 Markings: PAIGE #459842NH LSZH 24AWG 2PR SHIELDED 75’C 300V ROHS II
       COMPLIANT REACH MADE IN USA (Ascending/Descending footage markings)

 8. Electricals

 8.1 Impedance: 120 ohms
 8.2 Capacitance: 12.75 pF/ft.
 8.3 DC Resistance: 24.5 ohms/M ft. @ 20degC
 8.4 Voltage Rating: 300 Volt

 Scope

 This cable consists of 2 pairs 24 AWG stranded tinned copper; color-coded Polyethylene insulation; overall
 aluminum Mylar shield with drain wire; tinned copper braid; overall Low Smoke Zero Halogen Polyolefin jacket.
 RoHS II & REACH Compliant
