HAGER LATCHING RELAY

   Characteristics

   Permits the remote control of a lighting circuits from several points  using push-buttons in private buildings, small industry buildings and administration   buildings. Latching relays operate when impulsed by a signal voltage. The impulse can be provided via a push button or switch. The first pulse operates the     relay and latches it into its set (opposite) state, the next operation of the push button returns the relay into its reset (original) state.

   Technical Data

     - nominal voltage of the power circuit: Un = 250/400 V AC
     - nominal voltage of the power circuit: 12V, 24V, 48V and 230 V AC
     - nominal voltage of the control circuit: 12V, 24V, 110V DC
     - conventional thermal current: 16A AC1
     - control and power circuits
     - nominal frequency: 50/60Hz
     - contact types: 1NO, 2NO, 1NC+1NO, 4NO, 2NO+2NC, 3NO+1NC
     - 4 types of auxiliaries

 Typical applications are:

  Latching relays are used in a wide variety of applications, including:

  Industrial automation
  Lighting control
  Security systems
  Automotive applications

 Weight :

 Dimetion :

 Cable in one drum:

 Pallet weight :

 Total net weight in cluding both :
