Plain annealed copper wire, solid class 1 or stranded class 2 according to EN 60228.
High performance fire resistant silicone rubber type EI2 to BS EN 50363-1.
insulated cores are cabled together.
Uninsulated tinned copper conductor, 0,5 mm2
LSZH thermoplastic material type LTS3 according BS 7655.
Colour red or white (other colours on request)
Colour code upto 4 Cores to HD
-40°C to +90°C
FIRECEL SR 104 are primarily intended for general application.
Typical applications are:
Fire detection and fire alarm systems for building, voice alarm, emergency voice communication, emergency lighting and central battery systems.
Cable in one drum:
Pallet weight :
Total net weight in cluding both :
yesr with details to be provided
Replacement not allowed
