Fluke ScopeMeter Digital Oscilloscope, 190-062-UK, 2 Input Channel, 60MHz

 KEY FEATURES

 ·  Input voltage: CAT III 1000 V / CAT IV 600 V safety-rated

 ·  Bandwidth: 60 MHz

 ·  Number of Channels: 2

 ·  Maximum real-time sample rate: 625 MS/s

 ·  Operating temperature

    0°C to 40°C Including Batteries

    0°C to 50°C Excluding Batteries

 ·  Deep memory: 10,000 samples per channel waveform capture so you can zoom in on the details

 ·  Dedicated 5000 Count digital multimeter

 · Two electrically isolated inputs

 ·  Connect-and-View continuous auto-trigger, single shot, pulse width, and video triggering

 ·  ScopeRecord roll mode, capture waveform sample data for up to 48 hours

 ·  TrendPlot, trend measurement readings for up to 22 days

 ·  Advanced automatic measurements, power (Vpwm, VA, W, PF), and time (mAs, V/s, w/s)

 ·  IP-51 is rated for dust and drip-proof to withstand harsh environments

 ·  Isolated USB ports for memory devices and PC connectivity

 ·  Li-Ion battery for extended operating timespan: up to 4 hours (BP290 included standard) or up to 8 hours with optional BP291

 ·  Charge spare battery using optional external battery charger (EBC290)

 ·  Easy-access battery door to make it easy to swap batteries

 ·  A handy slot to tether and lock down the oscilloscope while unattended using a standard Kensingston lock

 Application

 Inspect input signals, output feedback loops, or safety interlocks simultaneously to find a range of problems including

 Circuit voltage/current overloading

 Signal timing measurements and synchronization issues

 Attenuation/input impedance mismatch

 Signal fluctuation/drift\

 Three-phase testing for diagnosing VSD, power inverters, and converters

 Test for harmonics, transients, and loads at the three-phase power input

 Troubleshoot DC to AC converters for faulty IGBT gates or filter circuits

 Test PWM output for reflections and transients or voltage imbalance
